002412002
ZE 8V Bell / Buzzer
- ETI Code:
- 002412002
- Rated DC voltage:
- 24 V
- Rated Frequency:
- 50/60 Hz
- Standards:
- IEC/EN 60947-1, IEC/EN 60947-3
- Application:
- IEC/EN 60947-1, IEC/EN 60947-3
- IP rating:
- IP20
- Utilization category:
- AC-22A
- Max input cross-section:
- 6 mm²
- Catalogue Group:
- Bell/Buzzer/Bell transformer
- Catalogue Subgroup:
- Bell/Buzzer
- Function:
- Bell/Buzzer
5 Documents
16 Logistics
Product
- EAN code for a single product
- 3838895826675
- Net weight of the product
- 0.076 kg
- Net width
- 17.6 mm
- Net height
- 84.5 mm
- Net depth
- 63.2 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 12 pcs
- EAN code for a basic packaging
- 3838895299356
- Basic packaging weight
- 0.97 kg
- Basic packaging volume
- 1.47 dm³
Transport Packaging
- Transport packaging quantity
- 108 pcs
- EAN code for a transport packaging
- 3838895299394
- Transport packaging weight
- 9.08 kg
- Transport packaging volume
- 17.4 dm³
- Pallet quantity
- 5,616 pcs
- Customs tariff
- 85318040
7 ETIM
- Housing colour
- Grey
- Degree of protection (IP)
- IP20
- Housing material
- Plastic
- Loudness
- 75 dB
- Width in number of modular spacings
- 1
- Nominal voltage(Min)
- 8 V
- Nominal voltage(Max)
- 8 V
ETIM Classification – Version 9.0
1 Diagrams
1 Software & drivers
Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
16 Tags
002412002Bell / BuzzerZE 8VEVE/ETIRELBuild-in deviceEVESYSEVESYSBell/BuzzerBell/BuzzerInternationalAutomation, signaling and control devicesBuzzers and bell transformers EVESYSCatalogue Subgroup: Bell/BuzzerFunction: Bell/BuzzerCatalogue Group: Bell/Buzzer/Bell transformerBell / Buzzer TOWAR Catalogue Group: Bell/Buzzer/Bell transformer Catalogue Subgroup: Bell/Buzzer Function: Bell/Buzzer
