002625046
CH10x38 gRSE 16A/690V Fuse link
- ETI Code:
- 002625046
- Product group:
- Special purpose fuses
- Catalogue Group:
- Special purpose fuses
- Fuse type:
- CH
- Type description:
- CH
- Size:
- 10x38
- Rated current:
- 16 A
- Time-Current Characteristic:
- gR
- Rated AC voltage:
- 690 V
- Breaking capacity AC:
- 100 kA
- L/R:
- 10 ms
- Power dissipation (0,7xIn):
- 1.6 W
- Power dissipation:
- 2.8 W
- Prearcing joule integral (A2s):
- 32
- Operating joule integral (A2s):
- 166
- Standards:
- IEC 60269-4
- Application:
- Protection of inverters, variable speed drives
5 Documents
22 Logistics
Product
- EAN code for a single product
- 3838400060983
- Net weight of the product
- 8.3 g
- Net width
- 10.2 mm
- Net height
- 38.2 mm
- Net depth
- 10.2 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 10 pcs
- EAN code for a basic packaging
- 3838895695004
- Basic packaging weight
- 0.088 kg
- Basic Packaging Dimensions Height
- 11 mm
- Basic Packaging Dimensions Width
- 54 mm
- Basic Packaging Dimensions Depth
- 77.5 mm
- Basic packaging volume
- 0.046 dm³
Transport Packaging
- Transport packaging quantity
- 500 pcs
- EAN code for a transport packaging
- 3838895695011
- Transport packaging weight
- 4.481 kg
- Transport Packaging Dimensions Height
- 285 mm
- Transport Packaging Dimensions Width
- 343 mm
- Transport Packaging Dimensions Depth
- 363 mm
- Transport packaging volume
- 35.485 dm³
- Pallet quantity
- 85,000 pcs
- Customs tariff
- 85361050
4 ETIM
- Size
- 10x32 mm
- Breaking capacity
- 100 kA
- Rated current
- 16 A
- Utilization category
- Other
ETIM Classification – Version 9.0
