002635007
CH14x51 aR 10A/690V Fuse link
- ETI Code:
- 002635007
- Product group:
- Semiconductor Protection
- Catalogue Group:
- Semiconductor Protection
- Fuse type:
- CH
- Type description:
- CH
- Size:
- 14x51
- Rated current:
- 10 A
- Time-Current Characteristic:
- aR
- Rated AC voltage:
- 690 V
- Rated DC voltage:
- 700 V
- Breaking capacity AC:
- 200 kA
- Breaking capacity DC:
- 50 kA
- Power dissipation:
- 4 W
- Operating joule integral (A2s):
- 22
- Standards:
- IEC 60269-4
- Application:
- For protection of semiconductor devices
5 Documents
15 Logistics
Product
- EAN code for a single product
- 3838895362500
- Net weight of the product
- 0.039 kg
- Net width
- 14.3 mm
- Net height
- 51 mm
- Net depth
- 14.3 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 10 pcs
- EAN code for a transport packaging
- 3838895356233
- Transport packaging weight
- 0.19 kg
- Transport Packaging Dimensions Height
- 16 mm
- Transport Packaging Dimensions Width
- 75 mm
- Transport Packaging Dimensions Depth
- 105 mm
- Transport packaging volume
- 0.126 dm³
- Pallet quantity
- 70,000 pcs
- Customs tariff
- 85361010
4 ETIM
- Size
- 14x51 mm
- Breaking capacity
- 200 kA
- Rated current
- 10 A
- Utilization category
- Other
ETIM Classification – Version 9.0
